Description
The Split 3 Micro HD FPV Camera is a compact 2-in-1 solution designed for drone pilots who want both a real-time FPV feed and onboard HD recording in a lightweight package. Built for racing drones, freestyle builds, and compact UAV platforms, the Split 3 Micro delivers smooth low-latency FPV video while simultaneously recording high-definition footage to a microSD card.
With 1080p recording at up to 60fps, the Split 3 Micro allows pilots to capture crisp aerial footage without the need for a separate HD action camera. Its micro-sized camera module and lightweight DVR board make it ideal for tight builds where space and weight are critical. The camera integrates easily with most popular flight controllers and supports UART control for adjusting settings directly through your drone configuration.
Thanks to its wide dynamic range (WDR) image processing, the Split 3 Micro performs well in varying lighting conditions, maintaining detail in both bright skies and darker ground environments. The camera also features a wide voltage input range, making it compatible with a variety of drone power systems used in FPV racing, freestyle, and long-range builds.
Whether you’re building a compact freestyle quad or upgrading an existing FPV setup, the Split 3 Micro offers reliable HD recording and responsive FPV performance in a small and efficient design.
What’s Included
1 × Split 3 Micro Camera
1 × DVR Processing Board
1 × 19-28mm Mounting Bracket
1 × JST 3-Pin Cable
1 × Set of Screws
1 × User Manual
Shipping & Support:
Ships from NY, USA & Carefully packed by MobileTechSpecialists
FPV setup assistance available upon request
Looking for more FPV cameras? Browse our full selection of FPV drone parts here.
Specifications
| FOV Angle of Field | FPV FOV 130° / Recording FOV 165° |
| Video Resolution | 1080@60fps / 1080@30fps / 720@60fps |
| Video Files | MOV |
| Image Resolution | 2 Megapixels |
| TV Output | NTSC / PAL Switchable |
| Real-Time Audio Output | Yes |
| Interface | Micro USB / UART |
| Max Micro SD Card Supported | 64G(need Class 6 or above, recommend Class 10/UHS-I/UHS-II) |
| WiFi Module | Support (Removable) |
| Dimensions | PCB 36*38mm / Lens Module 22*20mm |
| Power Input | DC 5V |
| Working Current | 650 mAh |
| Weight | 21g |
Questions & Answers
Q: What does the RunCam Split 3 do?
A: It is a 2-in-1 micro FPV camera that gives you a real-time low-latency FPV feed (about 40 ms) while simultaneously recording 1080p HD footage to a microSD card, so you do not need a separate HD action camera.
Q: What video resolutions does it record?
A: 1080p at 60fps, 1080p at 30fps, and 720p at 60fps, saved as MOV files. TV output is NTSC/PAL switchable.
Q: What is included in the box?
A: One Split 3 Micro camera, one DVR processing board, one 19-28mm mounting bracket, one JST 3-pin cable, a set of screws, and a user manual. A microSD card is not included.
Q: What microSD card does it support?
A: microSD cards up to 64GB. The listing specifies Class 6 or above, and recommends Class 10 or UHS-I/UHS-II.
Q: How fast is shipping?
A: Orders ship from NY, USA in 24-48 hours. US shipping is free on orders over $100.







Reviews
There are no reviews yet.
